Sheet Metal Membrane Roof Panel with PUR-PIR Insulation
Overview
It offers much faster, easier and more economical installation compared to on-site applications. • It is a highly fire-resistant roofing material that provides the necessary water and heat insulation on roofs with a low slope (minimum 1.5% slope).
- In the Sheet Metal Membrane Roof Panel, the membrane adheres directly to the metal and not to a filling material.
- It has high compression strength and eliminates the weakness of waterproofing by preventing deformation, scars and folds that may occur on the membrane surface.
- With its double-sided sheet metal structure, it has a higher load-carrying capacity than standard membrane panels. • It can be preferred with PVC or TPO membranes. • It is produced with PIR, PUR, and rock wool filling alternatives.
Technical Specifications
- Insulation Thicknesses
- 40-50-60-75-80-100-120mm
- Insulation Density
- PUR 40 (±2) kg/m3
- PIR 42 (±2) kg/m3
- Metal Thickness/Inner Surface/BGS
- 0.50-0.60-0.70-0.80 mm
- Metal Thickness/External Surface/BGS
- 1.2 - 1.5 mm
- TPO or PVC membrane
- Thermal Conductivity Coefficient
- λ = 0.022 W/mK
- Fire Class/PUR
- PUR B-s2, d0 EN 13501-1
- Fire Class/PIR
- PIR B-s1, d0 EN 13501-1
